Displays Radar Targets:
- Range is adjustable
- Up to 8 targets
Calculates Global Coordinates:
- All 8 targets
- Includes altitude
- Accounts for pitch axis
- Target Detected Passthrough
Size:
2x5
Nodes:
-Composite In: Radar
- Composite Out: Global Coordinates
- Video Out: Monitor
- Number In: Radar Rotation
- Number In: GPS X
- Number In: GPS Y
- Number In: Altitude
- Number In: Compass
- Number In: Tilt
- Number In: Radar Range to be displayed
Instructions:
- Connect Everything (obviously)
- Set radar range in the properties to same as radar
- Tilt and Compass Sensors need to be facing in same direction as radar
- Tilt Sensor Arrows flat face should be facing to the sides
- Place all sensors as close as possible to radar
Additional Info:
- If you only want to use the radar display, dont connect: tilt, compass, gps x/y, altitude.
- Radar Display Range can be left unconnected to always use max radar range.
