Modular Engine Control Unit
This microcontroller is free to use and I need no credit if you use it in your own creation(s).
[Please note that there is a more advanced version of this control unit which comes with a rps limiter]
An easy to set up and use microcontroller that can be used in both variable throttle applications (vehicle propulsion) and fixed throttle applications (generators). everything is labelled properly.
The properties menu has two modifiable values: "Air Manifold Modifier" and "Fuel Manifold Modifier" which allow you to change the air-fuel ratio and also adjust max power output.
The standard values for a modular engine are 0.5 for fuel and 1.0 for air.
For engines using forced induction a Fuel Manifold Modifier of 0.6-0.8 is recommended.
There are a few outputs: "Engine RPM", "Clutch", "Air Manifold(s)" and "Fuel Manifold(s)"
And a few number inputs: "Engine RPS" and "Throttle"
And finally a couple of on/off inputs: "Ignition" and "Throttle Override"
This is to help streamline the process of setting up a modular engine, and this microcontroller will work with any of the three sizes (1x1, 3x3, 5x5).
