Pylon Controller
11 Pylon System using a Panel with 2 Seven Segments
- All 1-11 Fire outputs go to hard-point launch signals
- All 1-11 Release outputs go to hard-point release signals
(B) = Binary On/Off
(N) = Number
--- Panel Channels ---
Ch 1 - Right side Seven Segment (Left to Right) (N)
Ch 2 - Left side Seven Segment (Left to Right) (N)
Ch 3 - Selection Up (Push Button) (B)
Ch 4 - Selection Down (Push Button) (B)
--- Seat Channels ---
Ch 1 - Master Arm (Seat Hotkey 1) (B)
Ch 2 - Release Selected Pylon (Seat Hotkey 2) (B)
Ch 3 - Release All Pylons (Seat Hotkey 3) (B)
